HANDHELD & SCANNING DENSITOMETER

  • Fast, accurate, and designed for convenience
  • Measure spot colors, density or scan color bars
  • View density variation across press width
  • Verify proofs against ISO and other standards
  • Maintain G7 neutral values with control strip
  • Evaluate critical brand colors
  • Connect with desktop software over Wi-Fi

SIX reasons YOU NEED the SpectroDens
  1. 1. STANDARDS COMPLIANCY: The SpectroDens densitometer and spectrophotometer includes full support for ISO and G7® methodologies, and fulfills M0, M1, M2, M3 measuring conditions in accordance to ISO 13655.
  2. 2. SPEED: The innovative measurement head allows a single spot measurement approximately every 1 second while the patented, side-aperture design lets you easily position the optics over the desired measurement location for even faster operation.
  3. 3. ACCURACY: The high-resolution spectral engine enables spectral sampling in 10 nm intervals from 400 nm to 700 nm
  4. 4. VERSATILITY: Seamlessly switch between spot measurements and color bar scanning up to 43-inches long, with the push of a button, and without the need for additional accessories.
  5. 5. ERGONOMICS: As well as being comfortable and easy to use, no moving parts means the solid state spectral engine can deliver unbeatable measurement accuracy and repeatability over time
  6. 6. 2018 INTERTECH AWARD WINNER: The judges liked its unique “combination of super-fast measurement speeds, heightened intelligence, and a built-in mode for color bar scanning” and concluded the “foresee SpectroDens4 becoming the spectrophotometer of choice in many pressrooms.”


SPECTRODENS HIGHLIGHTS

QUICK MEASUREMENT OF PROCESS AND SPOT COLORS

Control your process, spot, Pantone® or other critical brand colors by measuring solid ink density, % dot area, CIE Lab, deltaE, and more.

TRACK DENSITIES ACROSS SHEET

Shows density variation across press sheet and provides specific ink key adjustments right on instrument display.

BEST COLOR MATCH

InkCheck™ feature helps press operators minimize color differences (deltaE’s) by providing specific density adjustments to achieve best possible color matches.

SPOT AND SCAN MEASUREMENT IN SAME DEVICE

Switch from spot measurements to color bar scanning with the touch of a button. Scan color bars up to 43-inches long in only 10 seconds (200 patch maximum); no guide required, 4 wheels keep straight alignment while scanning.

ACHIEVE G7 COMPLIANCE

GrayGuide™ feature displays G7 pass/fail indication and specific C,M,Y density adjustments to obtain grayscale values according to G7 specification.

SCAN MEDIA WEDGE FOR QUICK PROOF VERIFICATION

Scan control wedge in seconds to confirm proofs against 12647-7 and known datasets like GRACol, SWOP3, SWOP5, IFRA, UGRA/FOGRA, G7™, etc.

DESKTOP SOFTWARE INCLUDED

Create, edit, and manage color libraries, import/export color data, generate pass/fail QC reports, and manage instrument, all with SpectroConnect.

TAILORED TO MEET YOUR NEEDS

The SpectroDens is available in 3 different models to best meet your color measurement needs (model comparison below).

HIGH-RESOLUTION & NIST TRACEABLE

Spectral sampling in 10 nm intervals from 400 nm to 700 nm fully complies with ISO-13655 requirements.

SOLID ALUMINUM UNIBODY CASE

The unibody case is machined from a single block of aluminum to maximize durability and reliability in harsh production environments.
